Double-sided scarfing insert, square with a main cutting edge length of 19.05mm, 8.15mm thick and a working radius of 90mm for tube diameters from 104 to 131mm, 6640 MT-CVD coated WC-Co carbide within ISO-grade ranges P20-P40 and M20-M35 for deburring the outside of steel and stainless-steel tubes and pipes
- Product Name ISO: SNMX 19-R90:6640
- Ordering Code ANSI: SNMX 19-R90:6640
- EDP Number: 6752123
- Coating: 6640
- Material Application Priority Usage: P - Steel and cast steel (steels with alloy content = 10% and a hardness of < 45HRC)
| Quick Ship Items | No, but I will Ship Soon |
| Product Measurement Standard | Metric |
| Fixing Hole Diameter (Mm.) | 7.95 |
| Inscribing Circle Dia. (Mm.) | 19.05 |
| Insert Thickness (Mm.) | 8.15 |
| Coating | 6640 |
