4 FL Standard Length - Series UGMG53 V7 Plus A Multi Helix Ball Nose Plain Shank End Mill - 1/4x1/4x1/2x2-1/2
- Application: P, M, K, S
- High-performance solid carbide construction for durability and consistent cutting in demanding applications
- Optimized for steels, stainless steel, cast iron, and high-temp alloys, making it a versatile production tool
- Designed for high productivity operations like slotting, profiling, and trochoidal milling with reduced vibration
| Quick Ship Items | No, but I will Ship Soon |
| Number of Flutes RH | 4 |
| Diameter Decimal (In.) | 0.25 |
| Diameter Decimal (Mm.) | 6.35 |
| Shank Diameter Decimal (In.) | 0.25 |
| Shank Diameter Decimal (Mm.) | 6.350 |
| Length of Cut (In.) | 0.750 |
| Length of Cut (Mm.) | 19.050 |
| Overall Length Decimal (In.) | 2.5 |
| Overall Length Decimal (Mm.) | 63.5 |
| Ball Nose Radius Decimal (In.) | 0.125 |
| Ball Nose Radius Decimal (Mm.) | 3.175 |
| Shank Type | Plain |
| Helix Angle | 45 |
| Coating | Y-Coating |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Product Measurement Standard | Inch |
