5FL NPT(F) Taper Pipe Tap - 3/4-14

5FL Striaght Flute Pipe Tap NPT/F TIN Coated

$119.33 excl tax

excl. VAT plus shipping

Order within 12 hrs 35 mins and this product can SHIP TOMORROW ON Wednesday, June 17!

Series R8 5FL Striaght Flute Pipe Tap NPT/F TIN Coated - NPT(F) Taper - 3/4-14

Connection (In.): 0.9063 x 0.679
Length/Diameter: 2.0 x D
Useable Length (In.): 1.38
High-speed steel construction for durability and long tool life in threading applications
Precision-ground threads ensure accurate, clean, and consistent pipe threads
Designed for use on a variety of materials including steel, stainless steel, and non-ferrous metals
Tapered design allows for proper sealing in pipe threading applications (NPT/NPTF standards)
Surface treatments/coatings improve wear resistance and reduce friction during cutting
Suitable for both hand tapping and machine tapping operations in industrial settings

Quick Ship Items	No, but I will Ship Soon
Chamfer Type	Modified Bottoming
Chamfer Length	2P-3P
Thread Diameter Size	3/4
Diameter Decimal (In.)	0.7500
Diameter Decimal (Mm.)	19.05
Pitch	14
Thread Series	NPTF
Material	HSSE-V3
Helix Angle	0
Overall Length Decimal (In.)	3.250
Overall Length Decimal (Mm.)	82.55
Thread Length Decimal (In.)	1.38
Thread Length Decimal (Mm.)	35.05
Square Length Decimal (In.)	0.69
Square Length Decimal (Mm.)	17.53
Shank Diameter Decimal (In.)	0.9063
Shank Diameter Decimal (Mm.)	23.02
Square Size Decimal (In.)	0.679
Square Size Decimal (Mm.)	17.25
Product Measurement Standard	Inch
Shank Type	Square
Drill Size Decimal (In.)	0.9063
Drill Size Decimal (Mm.)	23.02
Finish	TiN
