Single-sided positive turning insert, 35° rhomboid with 5° clearance, inscribed circle diameter of 9.525mm, 4.76mm thick, 0.4mm nose radius, indexing accuracy according to ISO-tolerance class-M, chip-breaker FM with rounded cutting edges, in grade T8430, a PVD coated fine grained WC-Co carbide within ISO ranges P20 -P40 and M20 -M35, for fine to medium machining of steels and stainless-steels
- Product Name ISO: VBMT 160404E-FM:T8430
- Ordering Code ANSI: VBMT 331-FM:T8430
- EDP Number: 7973869
- Coating: T8430
- Material Application Priority Usage: M - Stainless steel (corrosion resistant steels with = 11% chromium content), P - Steel and cast steel (steels with alloy content = 10% and a hardness of < 45HRC)
| Product Measurement Standard | Metric |
| Corner Radius (Mm.) | 0.4 |
| Fixing Hole Diameter (Mm.) | 4.4 |
| Inscribing Circle Dia. (Mm.) | 9.525 |
| Insert Thickness (Mm.) | 4.76 |
| Insert Geometry | Positive |
| Coating | T8430 |
There are no reviews yet
Customers who bought this item also bought
Turning Insert - Negative - DNMG 432-M:T9415
$14.68 excl tax
Glove Spandex w/ Palm Nitrile – L
From $1.95 excl tax
Turning Insert - Positive - DCMT 32.52-FM:T8430
$10.62 excl tax
Insert AOMT184808PEER-H MP6130
$20.65 excl tax
Insert SRM216C-M VP15TF
$43.86 excl tax
Insert L54 4P 1TPF V038 Ext RH 613
$42.14 excl tax
Insert TNEGX 54 2534 Grade 613
$38.75 excl tax
Milling Insert - Square Shoulder - AOMT 184808-H:SM5015
$15.82 excl tax
Insert TNMG 543RP MC6135
$33.29 excl tax
New
Endmill 4FL Multi Helix Ball Plain Shank - 1/8x1/8x1/2x2-1/2
$31.63 excl tax
TuffCut XR 5 Flute End Mill - 3/8x1/2x2x.030R ALtima
